在线折光仪传感器：
L-Rix

The process connection O-ring for the L-Rix 3x00 ensures a reliable seal between the L-Rix 3x00 and the process connection. It prevents the leakage of liquids and ensures a secure connection in industrial applications. Scope of delivery 1 pc. L-Rix 3X00 Process Connection O-Ring Technical specification
- Material: EPDM
- Compound Code: EPDM 70.503-00
- Inner Diameter (d₁): 25 mm
- Cross-Section (d₂): 2 mm
- Operating Temperature (Air): -57 °C to 150 °C
- Hardness: Shore A
- Compliance: 3-A Sanitary Standard No. 18-03 Class II;
FDA CFR 21 - 177.2600 "Rubber articles intended for repeated use"
- Color: Black

Process refractometer for monitoring sugar concentration and temperature. It is specifically designed for monitoring cooling lubricants and quenching media. Measuring principle without moving parts is maintenance-free with minimal operating costs. Scope of delivery 1 pcs. L-Rix 2100 Transmitter 1 pcs. Sensor protection cap 1 pcs. M12 protection cap 1 pcs. Instruction Manual 1 pcs. Calibration data sheet Technical specification
- Accuracy: ±0.0003 nD (equivalent to ± 0.2 % mass)
- Repeatability: ±0.00015 nD (equivalent to ± 0.1 % mass)
- Refractive index range: 1.3268 to 1.3830 nD
- Sugar range: 0 to 30 %
- Process temperature: 0 °C to 60 °C
- Process pressure: 100 mbara to 10 bara
- Ambient temperature: -5 °C to 55 °C
- Wetted parts: Stainless steel 1.4305, PEEK, Sapphire
- Protection rating: IP65; IP67
- Process connection: G1" Male, according to DIN/ISO 228
- Output Signal: Dual-channel analog (4–20 mA) or IO-Link
